LED Lighting
Experience Our Slient DC Fans for Your Commercial LED Lighting to Avoid Unconformtable Noise to Your Customers.
Our Fan Applications
Need Any Help?
Can not find the suitable models here? There are only some popular models for 3D printer. Contact us to get the right DC fans for your need.
About DC Fan Solutions in LED Lighting
- Low Noise: For DC fan used in LED Lighting, normally that requires low noise. We have a full range of DC fan with different sizes and on one size, there are different series with different imepeller designs, which can perfectly meet your needs. Additionally, we can offer support to help our customer to test the whole LED noise by different lamp surfaces.
- High Customization: We have suecessful cases to integrate our frame design into the aluminum parts from customer side to make the assembly easy and cost saving.
What's the fan size and spec. we offer?
| Fan Size | Normal Voltage | Bearing Type | Max. Power | Max. Speed | Max. Air Flow (cfm) | Max. Air Pressure (mmH2O) | Max. Noise (dBA) |
|---|---|---|---|---|---|---|---|
| 35x35x10mm Square Series B | 5V/9V/12V/24V | Rifle/Two-Ball | 1.08W(12V) | 9500RPM | 5.72 | 5.97 | 32.30 |
| 40x40x10mm Square 5 Fins | 5V/12V/24V | Rifle | 1.00W(5V) | 12700RPM | 11.84 | 11.71 | 33.18 |
| 40x40x10mm Square 7 Fins | 5V/12V/24V | Rifle/Two-Ball | 0.72W(24V) | 7200RPM | 7.07 | 5.57 | 31.30 |
| 40x40x10mm Square 11 Fins | 5V/12V/24V | Rifle/Two-Ball | 1.70W(5V) | 8000RPM | 7.73 | 5.32 | 31.50 |
| 40x40x15mm Square | 5V/12V/24V | Rifle/Two-Ball | 1.44W(12V) | 9800RPM | 11.63 | 12.22 | 36.90 |
| 50x50x10mm Square Series A | 12V/24V | Rifle/Two-Ball | 1.68W(12V) | 7000RPM | 11.31 | 5.15 | 37.80 |
| 50x50x15mm Square Series B | 12V/24V | Rifle/Two-Ball | 1.68W(12V) | 7500RPM | 16.25 | 8.76 | 39.50 |
| 60x60x10mm Square Series A | 5V/12V/24V | Rifle/Two-Ball | 1.20W(12V) | 5000RPM | 16.97 | 3.40 | 32.50 |
| 60x60x10mm Square Series C | 5V/12V/24V | Rifle/Two-Ball | 1.68W(5V) | 5500RPM | 23.22 | 5.24 | 39.60 |
| 60x60x15mm Series B - 7 Fins | 5V/12V/24V | Rifle | 3.36W(12V) | 6000RPM | 27.71 | 5.45 | 40.00 |
| 60x60x15mm Series C - 9 Fins | 5V/12V/24V | Rifle/Two-Ball | 3.84W(24V) | 6000RPM | 27.71 | 5.45 | 43.00 |
| 60x60x15mm Series D - 9 Fins | 5V/12V/24V | Rifle/Two-Ball | 3.36W(24V) | 6000RPM | 24.93 | 9.51 | 44.20 |
| 60x60x15mm Series E - 9 Fins | 5V/12V/24V | Rifle | 3.36W(24V) | 5500RPM | 25.01 | 7.37 | 36.90 |
| 80x80x15mm Series A - 11 Fins | 12V/24V | Rifle/Two-Ball | 2.88W(12V) | 3700RPM | 38.18 | 4.28 | 39.60 |
| 80x80x15mm Series C - 11 Fins | 12V/24V | Rifle | 4.68W(12V) | 3800RPM | 30.20 | 4.40 | 37.30 |
| 80x80X20mm Series D - 7 Fins | 12V/24V | Rifle | 1.92W(12V) | 3500RPM | 36.96 | 4.71 | 39.40 |
| 80x80X20mm Series E - 7 Fins | 12V/24V | Rifle/Two-Ball | 2.52W(12V) | 4000RPM | 41.81 | 5.81 | 37.80 |
| 80x80X25mm Series B - 7 Fins | 12V/24V | Rifle/Two-Ball | 2.28W(12V) | 3500RPM | 46.46 | 5.06 | 36.80 |
| 80x80X25mm Series C - 7 Fins | 12V/24V | Rifle/Two-Ball | 4.20W(12V) | 4100RPM | 55.71 | 6.80 | 43.90 |
| 92x92X25mm Series C - 7 Fins | 12V/24V | Rifle/Two-Ball | 2.94W(12V) | 2900RPM | 55.04 | 4.02 | 39.00 |
| 92x92X25mm Series F - 7 Fins | 12V/24V | Rifle/Two-Ball | 6.12W(12V) | 5000RPM | 80.08 | 12.42 | 46.90 |
